Lightweight Explosive Ordnance Disposal Robot
Lightweight Explosive Ordnance Disposal Robot
1, Product Overview
Explosive ordnance disposal robots are mainly used for handling explosive related work, and can also be used as a type of robot for reconnaissance of terrain that is difficult for humans to reach. The 7-degree-of-freedom bomb disposal robotic arm can rotate at different angles, with a maximum weight of 16KG at the proximal end and 3KG at the small gripper. The robotic arm can be loaded with an explosive destruction device and can destroy explosives on site. The chassis adopts a track+single swing arm structure, which can adapt to various terrains for rapid combat deployment. At the same time, the robot is equipped with wired control, which can work remotely through wired connections in the event of network interference. Explosive ordnance disposal robots can be used together with accessories, including destroyers (such as 29mm), remote detonation control systems for explosives, etc.
2,Product Features
1.★Mechanical arm preset and reset function
15 preset shortcut functions
1 one click reset function
2.★The robotic arm has multiple degrees of freedom
The robotic arm has 7 degrees of freedom
3.★Superior climbing, building climbing, obstacle crossing, and trench crossing performance
Can climb 45 degree slopes and 43 degree stairs
Can climb over a 30cm vertical obstacle
Can cross trenches with a width of 40 centimeters
4.★Mechanical arm grasping weight
The proximal end of the robotic arm can grip a maximum weight of 16kg
5.★Video System
Expandable 3-point communication method to solve normal combat in non visual environments, with a communication distance of 1km
4 high-definition cameras, 1 high-definition pan tilt zoom camera
6.★Modular design of the entire machine
Modular robotic arm
Battery modularization
Modular control box
7.★Product networking (optional)
Cloud platform remote management and monitoring
3,Technical parameters
3.1 Robot Machine:
1. Name: Lightweight Explosive Ordnance Disposal Robot
2. Model: ER3 9th generation
3. Basic functions: Explosive ordnance disposal, video reconnaissance function
4. Implement the police industry standard: “GA_T 142-1996″ General Technical Conditions for Explosive Ordnance Disposal Robots
5. ★ Protection level: Robot machine protection level IP65
6. Power: Electric, ternary lithium battery
7. ★ Size: ≤ 830mm in length, 600mm in width, and 450mm in height (in transit)
8. Turning diameter: Rotate in place
9. Whole machine weight: ≤ 37kg
10. Maximum speed in a straight line: ≥ 1.8m/s, remote control continuously variable transmission
11. Straight running deviation: ≤ 3%
12. Braking distance: ≤ 0.1m
13. ★★ Climbing ability: ≥ 45°
14. ★★ Climbing ability: ≥ 43°
15. ★ Trench crossing ability: ≥ 400mm
16. ★ Obstacle crossing height: ≥ 300mm
17. ★★ Water wading depth: 200mm
18. ★★ Continuous working time: ≥ 4h
19. Wireless remote control distance: ≥ 500m (through view)
20. Wireless video transmission distance: ≥ 500m (line of sight) two-point communication;
21. ★ Wired remote control distance: 100m (optional)
22. ★ Wired video transmission distance: 100m (optional)
23. ★ Load capacity: rated for grabbing 6KG heavy objects [maximum proximal grabbing 16KG]
