Fire rescue reconnaissance robot

                                                            Fire rescue reconnaissance robot

1. Product overview.

1.Main functions: The tracked explosion-proof robot chassis uses lithium battery power as its energy source and is operated remotely via wireless control. Equipped with a 6-degree-of-freedom bomb disposal manipulator, it can rotate at different angles and lift objects weighing up to 50 kg. Horizontally, it can handle objects weighing up to 10 kg. The robotic arm is also equipped with an explosive disposal device for on-site destruction of explosives. The track and single pendulum arm structure allows for rapid deployment in various terrains. Additionally, the robot is equipped with a radar life detection device, which uses electromagnetic waves to penetrate certain thicknesses of obstacles and detect vital signs of human survivors, such as breathing and heartbeat, in order to locate them.

2. Scope of application

Rescue operations for large-scale fires in petroleum and chemical enterprises:

Places prone to collapse, such as tunnels and subways, require entry for firefighting and rescue.

Rescue operations in environments with potential explosive gas or liquid leaks.

Rescue operations in environments with thick smoke or toxic gases.

Firefighting and rescue operations in close proximity, where personnel are at risk of injury.

3.Product features.

1.★ High explosion protection level

   Overall rating: Ex d ibIIB+H2T6 Gb

   Battery explosion protection level: Exd[ib] II CT6Gb

2.★ High protection level

   Overall protection level: IP67

   Chassis protection level: IP68

3.★ Intelligent detection

   Simultaneously detects multiple life forms and intelligently alerts for movement or stationary life forms.

   Detects 8 types of toxic and hazardous gases, as well as 2 environmental parameters.

4.★ Fast travel speed

   Reaches 6.51 km/h, which is 3 times higher than industry standards.

5.★ Versatile functionality

   Equipped for firefighting, reconnaissance, transportation, and especially for transporting rescue equipment and supplies (such as hoses, gas masks, positive pressure air respirators, firefighting suits, and breaking tools).

6.★ Integration with a robotic network cloud platform

   Real-time status information on the robot’s location, battery level, audio, and environmental detection can be transmitted to the cloud via 4G/5G networks, accessible from both PC and mobile devices.

7.★ Laser obstacle avoidance

   Detects up to 50 meters; operates at half speed within a 5-meter range, stops within 2 meters.

8.★ Mechanical arm preset positions and reset function

   3 quick preset positions

   1 single-button reset function

9.★ Multiple degrees of freedom for the mechanical arm (6 in total)

Company Information

Beijing Topsky Intelligent equipment Group Co.,Ltd.. (stock code: 836307) was founded in 2003, committed to making the world safer with innovative equipment, and determined to become a continuous leader in global high-end safety equipment.

Our company has independent R&D and technology promotion capabilities, and has one R&D and production building. Headquartered in Jinqiao Industrial Base, Zhongguancun High-tech Park, it is a national high-tech enterprise with a registered capital of RMB 46,514,300. Our company has independent R&D and manufacturing capabilities. Located in Beijing Economic Development Zone, the 3-story R&D building covers an area of 1,500 square meters, the production building is 1,800 square meters, and the third-phase production building is nearly 3,000 square meters under construction.

Our innovative technologies, services and systems are dedicated to serving the firefighting, law enforcement agencies, safety supervision bureaus, coal mines, petrochemicals. It involves the research and development of high-end equipment such as drones, robots, unmanned ships, special equipment, emergency rescue equipment, law enforcement equipment, and coal mine equipment.

So far, many products have been exported to more than 10 countries.
